8
Help line
If you have questions about AV 100 Plus:
• read this Instruction Manual carefully as it will allow you to solve most problems
• consult the www.meliconi.com website where you will fi nd all the answers you need quickly and easily.
PACKAGE CONTENTS
• 1 audio/video transmitter including an IN/OUT SCART connection cable and I.R. repeater
• 1 audio/video receiver including SCART connection cable
• 2 power adaptors: input voltage 230 V ~ 50Hz; output voltage 9 VDC 300 mA
• 1 instruction manual
AUDIO/VIDEO TRANSMISSION
-Audio/video transmission frequencies: from 5.725 to 5,875 GHz - 7 selectable channels
-Audio/video emission power: <20 mW (according to standard EN 300-440) France
-Modulation type: FM
-Video standards supported: PAL / NTSC / SECAM
-Number of channels: 7
-Adjustable antennae: array patch type
REMOTE CONTROL TRANSMISSION
-Transmission frequencies: 433.92 MHz
-Remote control emission power: <10 mW (according to standard EN 300-220) France
-Modulation type: ASK
-IR reception distance: up to 7 m
- IR signal repeaters = 2
-Integral aerials
-IR carrier: 32-57 KHz
TRANSMITTER
-SCART input connector: audio stereo / video CVBS
-SCART output connector: audio stereo / video CVBS
RECEIVER
-SCART output connector: audio stereo / video CVBS
-Video output signal: 1 Vpp typ / 75 Ohm
The product complies with the following directives:
Energy saving ErP 2009/125/CE.
Restriction of harmful substances (RoHS) 2002/95/CE .
Low voltage directive (LVD) 2006/95/CE.
EMC directive 2004/108/CE
Safety measures in compliance with norm EN 60065
R&TTE directives 1999/05/EC
