5
AV 100 Plus AV 100 Plus
Thank you for choosing MELICONI
The AV 100 Plus allows you to transmit a video signal in wireless mode from any audio/video source (SAT
decoder, DTT decoder, DVD player, video camera or VCR) to a second television in another room of the house.
You can also control up to two appliances connected to the main TV directly from the room in which the second
TV is located using a remote control.
NB: If you want to use an appliance with the AV 100 Plus it must have a SCART socket.
The AV 100 Plus consists of a transmitter to be connected to an appliance connected to the main TV, and a
receiver to be connected to the second TV. To distinguish between them, look for the words TRANSMITTER
and RECEIVER printed on the labels on the bottom of the products.
All connections must be made using SCART cables. To view the signal from the audio/video appliance
connected to the main TV, on the second TV, install the transmitter as indicated in Fig. 1 (basic confi guration).
If there are two appliances present (for example a SKY Decoder and a DVD player) install the transmitter as
indicated in Fig. 2 (advanced confi guration).
The AV 100 Plus transmitter includes an IN/OUT SCART adaptor. This allows you to view the same audio
video signal simultaneously on the main TV and the second TV without having to change the confi guration of
the sockets.
Product description
Installation
1. Plug the IN/OUT connector directly into the SCART OUT socket on the appliance you wish to transmit the
signal from. Connect the other end of the IN/OUT connector to the SCART cable connected to the TV (fi gure 1)
2. Set the twin channel selector on the back of the transmitter to one of the 7 available positions. The 4-position
selector on the back allows you to the select the required channel (1,3,5,7 or 2,4,6,X); the 2-position selector
on the left allows you to shift from the even number channels to the odd number ones.
CAUTION: the X position does not corresponds to any channel whatsoever
3. Plug the power adaptor connector into the corresponding socket at the back of the transmitter.
4. Plug the power adaptor into an easily accessible wall socket.
5. Position the transmitter near the television but not too near the other audio video appliances as they may
create interference. We recommend a distance of approximately 50 cm.
6. Switch the transmitter on using the switch on the back and check that the green warning light on the front
comes on.
7. Turn on the appliance connected to the AV 100 Plus, start it (ON or Power for the decoder, PLAY for the
videorecorder or DVD player,) and activate the audio/video input on the main TV using the remote control
(AV or EXT button) and check that the program running on the appliance can be seen.
Then install the receiver.
Installing the transmitter: main TV
GB
WARNINGS
• Keep away from water: the appliance should not be exposed to drips or splashes of water. Do not use
in a damp environment.
• In order to separate the device quickly from the electrical power supply, the plug on the power cable
should be easily accessible.
• Do not expose to excessive heat sources
• Do not cover the product
• Only use the power adaptors provided
• Connect the power adaptor only to a 230 V ~ 50Hz power supply
• Do not open the product
• The product is for internal use only: do not use outdoors
• Switch the transmitter and receiver off if you are not using them
• The product is not a toy: keep out of reach of children
IMPORTANT:
If your main TV has two SCART sockets, you can also choose to view the signal from one appliance on
the main TV, and at the same time send the signal from a second appliance to the second TV. Connect the
IN/OUT SCART adaptor on the AV 100 Plus transmitter to the appliance you wish to view on the second
TV. The other appliance should be connected directly to the main TV.
