7
On the main TV, you cannot see the picture from the appliance connected to the AV 100 Plus transmitter
IN/OUT SCART adaptor
• Check that the connections have been made correctly.
• Use the main TV remote control to activate the AV or EXT channel.
There is no picture on the second TV
• Check that the transmitter and receiver are both switched on.
• Check that the connections have been made correctly.
• Check that you have switched on the appliance you wish to watch on the second TV.
• Put the second TV onto the AV or EXT channel.
• Put the channel selector on the same number on the transmitter and the receiver.
There is poor quality picture or sound on the second TV
• Move the receiver and transmitter antennae until you get the best picture and sound.
• Move the channel selector to a different position on the transmitter and the receiver.
• Move the transmitter until you get the best picture and sound.
NOTE: in certain environments the best picture can be obtained by positioning the receiver and transmitter
antennae horizontally.
You cannot control the appliances connected to the main TV using the remote control
• Make sure the transmitter is not too near the other audio/video appliances (DVD, VCR player, decoder,
etc...).
• Check that you are using the remote control for the appliance you want to control.
• Make sure there is nothing between the remote control and the receiver and that they are not more than 7
metres apart.
• Check that the remote control repeater is positioned correctly.
• Check that there are no other wireless appliances that could interfere with the remote control.
Troubleshooting
Technical specifi cations
IMPORTANT:
• Sound and picture quality may be affected by microwave ovens, other electronic wireless systems or
electromagnetic radiation. Moreover, any metal items placed between the receiver and transmitter may
inhibit signal diffusion. The AV 100 Plus transmitter operates on 5.8 GHz band frequencies and therefore
does not interfere with WI-FI devices operating on the 2.4 GHz band (BLUETOOTH, wireless LAN etc.).
The signal that the transmitter sends to the receiver passes through walls and ceilings for a distance
of about 30 metres. Anyone using AV 100 Plus or a similar device (set on the same channel) near the
apartment could receive the same programmes you are watching (and vice versa) as the transmission is
not encrypted. In this case, we recommend you set the channel selector to a different channel on both the
receiver and the transmitter.
• If you wish to use only one remote control to command the appliances connected to the main TV from the
other room (if the advanced confi guration has been chosen), MELICONI offers a wide range of universal
remote controls for all brands of TV, decoder, VCR and DVD player. Consult the website www.meliconi.
com to fi nd which one best meets your requirements.
• Switch the transmitter and receiver off if you are not using them.
GENERAL
-Power supply: 230 V ~ 50Hz
-Consumption: 3,5W max for each device
-Average range indoors: 20 m (depending on the thickness of the walls)
-Maximum range without obstacles: 100 m
