24
• NFC communication lasts approximately 20 seconds.
Perform step 4 within 20 seconds of performing step 3 .
After 20 seconds have elapsed, NFC communication
automatically finishes and the GP/CH menu appears.
• During NFC communication, the signal from a wireless
microphone cannot be received.
Locking the POWER button (POWER
LOCK)
You can lock the POWER button to prevent the power
being turned off inadvertently during reception.
UNLOCK: Press and hold the POWER button to turn the
power on/off.
LOCK: The power does not turn off, even after pressing
the POWER button.
To release the lock state
To release the lock state, either set the POWER LOCK
menu to UNLOCK or use the following procedure.
1
When the button is in the LOCK state, press and hold
the POWER button.
A prompt appears asking you whether to release the
lock state.
2
Use the + or – button to select YES, then press the
SET button.
The lock state is released.
If the batteries are removed and reinserted while the
POWER button is set to LOCK, the power will turn on
automatically but the lock state of the POWER button
does not change.
Displaying the accumulated running time
(RUNNING TIME)
Displays the accumulated running time of the tuner as a
guide to total usage time.
The factory default setting is 00:00. Up to 99:99 can be
displayed.
To reset the time display
1
Press and hold the SET button until the time display
starts flashing.
2
Press the – button to display “00:00 CLR” and press
the SET button.
Pressing the + button when “00:00 CLR” is displayed
causes the time display to start flashing. You can
press the SET button in this state to cancel the reset of
the accumulated running time.
Setting the menu display mode (MENU
MODE)
Sets the menu display mode.
SIMPLE: Displays only the required settings.
ADVANCED: Displays all settings.
Using monitor audio level mode
(MONITOR MODE)
When this function is enabled, the display shows the
monitor audio level screen (fixed). Using the + or – button
changes the monitor audio level only.
1
Use the + or – button to display the MONITOR
MODE menu.
2
Press and hold the SET button for one second or
longer.
3
Use the + or – button to display “ON,” and press the
SET button.
Monitor audio level mode is activated, and is
displayed.
To release monitor audio level mode
1
Press and hold the SET button, POWER button, or
NFC SYNC button for one second or longer until
“ESCAPE?” is displayed.
2
Use the + or – button to display “YES,” and press the
SET button.
The lock state is released.
• This function is displayed in extended mode only.
• This function is released when the power is turned off.
Reconfigure the setting after the power is turned on.
Switching to the previous channel (CH
MEMORY)
You can switch to the previously set channel. This is
useful when using one tuner in combination with two
transmitters.
Set the channel you want to use beforehand.
For details about how to set the channel, see “Setting the
receive channel” (page 21).
1
Use the + or – button to display the CH MEMORY
menu.
2
Press and hold the SET button until “YES?” starts
flashing.
3
Press the SET button.
The previously set channel and the currently set
channel are displayed.
Notes
Note
Notes
