119
System settings
Setting the crosspoints
Assigning signals to the crosspoints
External video input signals and internally generated signals can be assigned to crosspoint buttons 1 to 24.
When one of the crosspoint buttons 1 to 24 is held down, the status of the signal assigned is displayed on the built-in display
while the button is held down.
Changing the current assignment of the signals selected by the crosspoint buttons will cause the positions of the lit crosspoint
buttons to change to correspond with the assignment change. The images output at this time will remain unchanged.
The table below lists the materials which can be assigned.
Signal
What appears on the
display
Description
IN1, IN2 IN1, IN2 SDI/HDMI input 1, 2
SDI IN3 to SDI IN8 SDI IN3 to SDI IN8 SDI input 3 to 8
IN-A1 to 4,
IN-B1 to 4 IN-A1 to 4,
IN-B1 to 4 Option slot (SDI, HDMI)
Black BLK Internally generated signal (black)
CBGD1, CBGD2 CBGD1, CBGD2 Internally generated signal (color background)
CBAR CBAR Internally generated signal (color bar)
Still1V, Still1K,
Still2V, Still2K Still1V, Still1K,
Still2V, Still2K Still image video memory
Clip1V, Clip1K,
Clip2V, Clip2K Clip1V, Clip1K,
Clip2V, Clip2K Moving image video memory
CLN CLN CLN (AUX bus and built-in display images only)
KeyOut KeyOut KeyOut (AUX bus and built-in display images only)
ME PGM ME PGM ME PGM (AUX bus and built-in display images only)
Shift SHIFT SHIFT function
None None No assignment
p The image will not be changed by pressing any button to which “None” is assigned.
The table below lists the default settings.
Button
What appears on
the display
Button
What appears on
the display
Button
What appears on
the display
XPT1 IN1 XPT9 CBAR XPT17 None
XPT2 IN2 XPT10 CBGD1 XPT18 None
XPT3 SDI IN 3 XPT11 CBGD2 XPT19 None
XPT4 SDI IN 4 XPT12 None XPT20 None
XPT5 SDI IN 5 XPT13 None XPT21 None
XPT6 SDI IN 6 XPT14 None XPT22 None
XPT7 SDI IN 7 XPT15 None XPT23 None
XPT8 SDI IN 8 XPT16 None XPT24 None
