J9144A-A
X2-LRM 10GB Module
1310nm, 220m, MMF, SC RoHS6
Pull-up Supply Voltage VPU 0.84 1.2 1.5 V
Input Capacitance CIN 10 pF
Load Capacitance CLOAD 470 pF
External Pull-up Resistance RLOAD 200 ?
1) For 1.8 V CMOS Voh= 1.65 V min., Vol= 0.15 V max., Vih= 1.17 V min., Vil= 0.63 V max.
2) Rpull-up = 10 k? to 1.8 V.
3) Vin = 1.8 V.
4) AC coupled.
5) IOL = 100 µA
Electrical AC Characteristics
(VCC5 = 4.75 V to 5.25 V, VCC3 = 3.14 V to 3.47 V, VCCaps= 1.152 V to 1.248 V, TC= 0°C to 70°C)
Parameter Symbol
Values Unit
min. typ. max.
XAUI Input AC Characteristics (TXLANE[0..3])
Baud Rate
RXAUIIN Gbit/s
Fibre Channel 3.1875
Ethernet 3.125
Baud Rate Tolerance RTOLXAUI –100 100 ppm
Differential Input Impedance ZINXAUI 80 100 120 ?
Differential Return Loss(1) |S11| 10 dB
Input Differential Skew(2) tSKEWIN 75 ps
Jitter Amplitude Tolerance(3) JXAUITOL 0.65 UIp-p
XAUI Output AC Characteristics (RXLANE[0..3])
Baud Rate Fibre Channel Ethernet
RXAUIOUT
3.1875
3.125
Gbit/s
Baud Rate Variation RXAUIVAR –100 100 ppm
XAUI Eye Mask (far-end) According to IEEE 802.3ae and 10G Fibre Channel
Output Differential Skew tSKEWOUT 15 ps
Output Differential Impedance ZOUTXAUI 80 100 120 ?
Differential Output Return Loss(1) |S22| 10 dB
Total Jitter4) TJXAUI 0.35 UI
Deterministic Jitter(4) DJXAUI 0.37 UI
Power-On Reset AC Characteristics
Power-On Reset and TX_ONOFF
Characteristics
According to X2 MSA Issue 3.0, 2002-9-18
MDIO I/O AC Characteristics (MDIO; MDC)
