Galaxy Power System GPS2436
Issue 1 August 2012 11
AC Panel
Circuit Breakers or
Terminal strip
Rectifier Shelves
3 , 6, or 9
Miscellaneous DC
Distribution Panels
Figure 2-4 GPS2436 Six shelf cabinet with door removed
