TL431/TL432
ADJUSTABLE PRECISION SHUNT REGULATOR
TL431 *SO-8 is a future package
Document number: DS35044 Rev. 6 - 2
10 of 14
www.diodes.com
April 2012
© Diodes Incorporated
Ordering Information
Device
Package
Code
Packaging
(Note 9)
7” Tape and Reel Ammo Box
Quantity
Part Number
Suffix
Quantity
Part Number
Suffix
TL431A(B)SA-7 SA SOT23 3000/Tape & Reel -7 NA NA
TL431A(B)W5-7 W5 SOT25 3000/Tape & Reel -7 NA NA
TL431A(B)S-13* S SO-8* 2500/Tape & Reel -13 NA NA
TL432A(B)SA-7 SA SOT23 3000/Tape & Reel -7 NA NA
* Suffix “B” denotes TL431B device.
Notes: 9. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
http://www.diodes.com/datasheets/ap02001.pdf.
