DMP3105LVT
Document number: DS35504 Rev. 2 - 2
2 of 6
November 2011
© Diodes Incorporated
DMP3105LVT
NEW PROD
UC
T
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Value
Units
Drain-Source Voltage
V
DSS
-30 V
Gate-Source Voltage
V
GSS
±12 V
Continuous Drain Current (Note 4) V
GS
= -10V
Steady
State
T
A
= 25°C
T
A
= 70°C
I
D
3.1
2.5
A
Continuous Drain Current (Note 4) V
GS
= -4.5V
Steady
State
T
A
= 25°C
T
A
= 70°C
I
D
2.7
2.2
A
Continuous Drain Current (Note 5) V
GS
= -10V
Steady
State
T
A
= 25°C
T
A
= 70°C
I
D
3.9
3.1
A
Continuous Drain Current (Note 5) V
GS
= -4.5V
Steady
State
T
A
= 25°C
T
A
= 70°C
I
D
3.3
2.7
A
Maximum Continuous Body Diode Forward Current
I
S
2.2 A
Pulsed Drain Current (10us pulse, duty cycle=1%)
I
DM
20 A
Thermal Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Value
Units
Total Power Dissipation (Note 4)
P
D
1.15 W
Thermal Resistance, Junction to Ambient (Note 4)
R
θJA
108 °C/W
Total Power Dissipation (Note 5)
P
D
1.75 W
Thermal Resistance, Junction to Ambient (Note 5)
R
θJA
72 °C/W
Thermal Resistance, Junction to Case (Note 5)
R
θJc
23.4 °C/W
Operating and Storage Temperature Range
T
J,
T
STG
-55 to +150
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
OFF CHARACTERISTICS (Note 6)
Drain-Source Breakdown Voltage
BV
DSS
-30
⎯
⎯
V
V
GS
= 0V, I
D
= -250
μA
Zero Gate Voltage Drain Current
I
DSS
⎯
⎯
-100
nA
V
DS
= -30V, V
GS
= 0V
Gate-Source Leakage
I
GSS
⎯
⎯
±100
nA
V
GS
=
±12V, V
DS
= 0V
ON CHARACTERISTICS (Note 6)
Gate Threshold Voltage
V
GS(th)
-0.5 -0.9 -1.5 V
V
DS
= V
GS
, I
D
= -250
μA
Static Drain-Source On-Resistance
R
DS (ON)
⎯
65 75
m
Ω
V
GS
= -10V, I
D
= -4.2A
⎯
75 98
V
GS
= -4.5V, I
D
= -4.0A
⎯
98 150
V
GS
= -2.5V, I
D
= -3.0A
Forward Transfer Admittance
|Y
fs
|
⎯
5
⎯
S
V
DS
= -15V, I
D
= -4.0A
Diode Forward Voltage
V
SD
⎯
-0.7 -1.0 V
V
GS
= 0V, I
S
= -1A
DYNAMIC CHARACTERISTICS (Note 7)
Input Capacitance
C
iss
⎯
839
⎯
pF
V
DS
= -15V, V
GS
= 0V
f = 1.0MHz
Output Capacitance
C
oss
⎯
47
⎯
Reverse Transfer Capacitance
C
rss
⎯
43
⎯
Gate Resistance
R
G
⎯
12.3
⎯
Ω
V
DS
= 0V, V
GS
= 0V, f = 1.0MHz
Total Gate Charge (V
GS
= -4.5V)
Q
g
⎯
9.0
⎯
nC
V
DS
= -15V, I
D
= -4.0A
Total Gate Charge
(V
GS
= -10.0V)
Q
g
⎯
19.8
⎯
Gate-Source Charge
Q
gs
⎯
1.6
⎯
Gate-Drain Charge
Q
gd
⎯
1.1
⎯
Turn-On Delay Time
t
D(on)
⎯
9.7
⎯
ns
V
GS
= -10V, V
DD
= -15V, R
G
= 6
Ω,
I
D
= -1A
Turn-On Rise Time
t
r
⎯
17.7
⎯
Turn-Off Delay Time
t
D(off)
⎯
269
⎯
Turn-Off Fall Time
t
f
⎯
64
⎯
Notes:
4. Device mounted on FR-4 PC board, with minimum recommended pad layout, single sided.
5. Device mounted on FR-4 substrate PC board, 2oz copper, with thermal vias to bottom layer 1inch square copper plate
6 .Short duration pulse test used to minimize self-heating effect.
7. Guaranteed by design. Not subject to production testing.
