A-4 INSTALLATION
MAXsa™ 19 CONTROLLER
A-4
FIGURE A.2 - MAXsa™ 19 COMPONENT DESCRIPTION CODE 11614
FIGURE A.2a - MAXsa™ 19 COMPONENT DESCRIPTION CODE 11778
14 Pin Connector
To Wire Drive
ArcLink Connector
To Power Source
External
I/O Connector
Status
LED
14 Pin Connector
To Wire Drive
ArcLink Connector
To Power Source
5 Socket
ArkLink Connector
External
I/O Connector
Status
LED
