46 GB
Specifications
Additional Information
Model name KDL-40X3500/
40X3000 KDL-46X3500/
46X3000 KDL-52X3500 KDL-70X3500
System
Panel System LCD (Liquid Crystal Display) Panel
TV System Analogue: Depending on your country/region selection: B/G/H, D/K, L, I
Digital: DVB-T/DVB-C
Colour/Video System Analogue: PAL, SECAM, NTSC 3.58, 4.43 (only Video In)
Digital: MPEG-2 MP@ML/HL, MPEG-4 HP@L3/L4
Channel Coverage Analogue: VHF: E2–E12/UHF: E21–E69/CATV: S1–S20/HYPER: S21–S41
D/K: R1–R12, R21–R69/L: F2–F10, B–Q, F21–F69/I: UHF B21–B69
Digital: VHF/UHF
Sound Output 11 W + 11 W
Input/Output jacks
Aerial/Cable 75 ohm external terminal for VHF/UHF
/ 1 21-pin scart connector (CENELEC standard) including audio/video input, RGB input, and TV audio/video
output.
/ 2 (SmartLink) 21-pin scart connector (CENELEC standard) including audio/video input, RGB input, selectable audio/video
output, and SmartLink interface.
3/ 4 Supported formats: 1080p, 1080i, 720p, 576p, 576i, 480p, 480i
Y: 1 Vp-p, 75 ohms, 0.3V negative sync/P
B /C B : 0.7 Vp-p, 75 ohms/
P R /C R : 0.7 Vp-p, 75 ohms
3/ 4 Audio input (phono jacks): 500 mVrms, Impedance: 47 kilohms
HDMI IN 5, 6, 8 Video: 1080/24p, 1080p, 1080i, 720p, 576p, 576i, 480p, 480i
Audio: Two channel linear PCM
32, 44.1 and 48 kHz, 16, 20 and 24 bits
Analogue audio input (phono jacks): 500 mVrms, Impedance: 47 kilohms (HDMI IN 5 only)
PC Input (see page 47)
7 S video input (4-pin mini DIN)
7 Video input (phono jack)
7 Audio input (phono jacks)
DIGITAL OUT (OPTICAL) (digital optical jack)/Audio output (phono jacks)
PC IN PC Input (D-sub 15-pin) (see page 47)
G: 0.7 Vp-p, 75 ohms, non Sync on Green/B: 0.7 Vp-p, 75 ohms/
R: 0.7 Vp-p, 75 ohms/HD: 1-5 Vp-p/VD: 1-5 Vp-p
PC audio input (minijack)
i Headphones jack
CAM (Conditional Access Module) slot
USB port
Power and others
Power Requirements 220–240 V AC, 50 Hz
Screen Size 40 inches (Approx.
101.6 cm measured
diagonally) 46 inches (Approx.
116.8 cm measured
diagonally) 52 inches (Approx.
132.2 cm measured
diagonally) 70 inches (Approx.
177.8 cm measured
diagonally)
Display Resolution 1,920 dots (horizontal) × 1,080 lines (vertical)
Power Consumption 240 W 285 W 320 W 630 W
Standby Power Consumption*
0.3 W 0.4 W
Dimensions
(w × h × d) (with stand) Approx. 1,111 Ч 717 Ч
322 mm Approx. 1,262 Ч 795 Ч
322 mm Approx. 1,415 Ч 890 Ч
384 mm Approx. 1,842 Ч 1,131 Ч
422 mm
(without stand) Approx. 1,111 Ч 657 Ч
123 mm (KDL-40X3500)
Approx. 1,111 Ч 657 Ч
121 mm (KDL-40X3000) Approx. 1,262 Ч 734 Ч
123 mm (KDL-46X3500)
Approx. 1,262 Ч 734 Ч
121 mm (KDL-46X3000)
Approx. 1,415 Ч 827 Ч
125 mm Approx. 1,842 Ч 1,073 Ч
150 mm
Mass (with stand) Approx. 31.0 kg Approx. 38.0 kg Approx. 49.0 kg Approx. 93.5 kg
(without stand) Approx. 26.0 kg Approx. 33.0 kg Approx. 42.0 kg Approx. 80.5 kg
Supplied Accessories
Refer to “1: Checking the accessories” on page 4.
Refer to “KDL-70X3500
Start-up Guide”.
