Dell Vostro 5460 (Late 2012) - Manual (Page 12)

b) base cover
3. Follow the procedures in After Working Inside Your Computer.
Removing the Coin-Cell Battery
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove :
a) base cover
b) battery
3. Disconnect the coin-cell battery cable from its connector on the system board.
4. Unroute the coin-cell battery cable from the routing channel.
5. Lift and remove the coin-cell from the computer.
Installing the Coin-Cell Battery
1. Place the coin-cell battery into its slot on the computer.
2. Route the coin-cell battery cable along the routing channel.
3. Connect the coin-cell battery cable to its connector on the system board.
4. Install :
a) battery
b) base cover
5. Follow the procedures in After Working Inside Your Computer.
Removing the Wireless Local Area Network (WLAN) Card
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove :
a) base cover
b) battery
3. Disconnect the antennae from the WLAN card.
4. Remove the screw that secures the WLAN card to the computer.
5. Remove the WLAN card from its slot on the system board.
12
