UM Enter the setup code.
^■'¡■Ultp:'U:iP
1D70VR/1050VR T^n/K)
MENU THE^ViE FAV
C
j
3^ CZ^ CZD
TV/SA^SD JNFO AOAUp
■ ^100 REPEAT RAryOOM
CD> CH^CE>
DISPLAY
Press POlVfff,
and check to see that the
component you want to control turns on.
m
Press the ENT key to store the code you
have just input.
Repeat steps 3 to 6 to register additional
components until all components have boon
registered.
Once setup codes have been entered for all
components, hold down the ENT key until
the backlight flashes twice.
> Example: Press 5258 to register a LD player made by KENWOOD.
'The beukliyhr
fldslies
once each time a nuntber is
entered.
• If an inyalid setup code is entered the remote will output one long blink,
disregard that code and return to the beginning of step 4.
• If you push an invalid key, the remote will exit the setup mode.
• PLAY
or
TUNING/SKIP
(+/-) can also be used instead of
POWER.
• It the component does not react, and there is more than one setup
code, enter another setup code and try again.
• If the component is already on, pressing
POWER
will turn it off.
> I his code replaces any previous setup codes entered for the respective
component.
• If you have components that are not remote controllable, like a record
player (etc.), you will need to register a Non-IR code at the respective
mput- This keeps the respective input in the remote control's cyclic list
so you can select it using the remote control. Please consult the
owner's manual of the components you are connecting for information
regarding remote controllability. The list of Non-IR codes is included at
the beginning of the Set up code chart.
• This operation should take about 3 seconds.
• Once registered, the display on the receiver shows the component
type instead of the default input name.
Example: if you register a VCR at the VIDEO 1 jacks,
"VCR"
appears
instead of
"VIDEO 1(SAT)"
• After initial setup, any VIDEO (VIDEO 1 , 2 , 3 ] or TV (TV1, TV2, CABLE)
nputs that have not been programmed with a setup code or Non-IR
code are deleted from lire cyclic iisr (excepL fur lire 'AV AUX^ VIDEO
nput). The PHONO input will be deleted if a Non-IR code was not
registered.
• The
INPUT SELECTOR
on the front panel of the receiver always cycles
through all inputs.
Although each setup code is designed to work with a number of different models, certain codes may not work with some models. (Also,
certain codes may only operate some of the functions available on a given model.)
