Safety
Operating Manual PNOZ mc7p
1003050-EN-01
7
Safety
Intended use
The fieldbus module PNOZ mc7p is an expansion module of the configurable control sys-
tem PNOZmulti. It is used for communication between the configurable control system
PNOZmulti and the
CC-Link .
CC-Link is designed for fast data exchange at field level. The expansion module CC-Link
is a passive subscriber (Slave) in CC-Link. The basic communication functions with CC-
Link conform to CC-Link V1.10. The central controller (master) reads input information from
the slaves and writes output information to the slaves as part of each cycle. As well as the
cyclical transfer of usable data, the expansion module
PNOZ mc7p also has diagnostic and
commissioning functions. Data traffic is monitored on the Master/Slave side.
The expansion module may only be connected to a base unit from the configurable control
system PNOZmulti (please refer to the document "PNOZmulti System Expansion" for de-
tails of the base units that can be connected)
The configurable control system PNOZmulti is used for the safety-related interruption of
safety circuits and is designed for use in:
} E-STOP equipment
} Safety circuits in accordance with VDE 0113 Part 1 and EN 60204-1
The expansion module may not be used for safety-related functions.
Intended use includes making the electrical installation EMC-compliant. The product is de-
signed for use in an industrial environment. It is not suitable for use in a domestic environ-
ment, as this can lead to interference.
The following is deemed improper use in particular:
} Any component, technical or electrical modification to the product
} Use of the product outside the areas described in this manual
} Use of the product outside the technical details (see chapter entitled “Technical De-
tails”)
System requirements
Please refer to the "Product Modifications" document in the "Version overview" section for
details of which versions of the base unit and PNOZmulti Configurator can be used for this
product.
Safety regulations
Use of qualified personnel
The products may only be assembled, installed, programmed, commissioned, operated,
maintained and decommissioned by competent persons.
A competent person is someone who, because of their training, experience and current pro-
fessional activity, has the specialist knowledge required to test, assess and operate the
work equipment, devices, systems, plant and machinery in accordance with the general
standards and guidelines for safety technology.
3
3.1
3.2
3.3
3.3.1
