2-1
2.1 Module structure
2 Overview
2 2000 Overview Overview 2- 2.1 Module structure 2100 Module structure 2- ][BA Übersicht Aufbau
A module consists of
 Electronic module and
 Base module with
– Screw terminals or
– Cage clamp terminals
The base modules are the carrier units for the electronic modules and
are used to connect the field wiring. The electronic modules are inserted
on to the base modules and determine the module's function.
Details of the base modules that can be used are available in the chapter
entitled “Intended Use”.
2.1.1 Module features
Module features 2- Geraetemerkmale_Zusatz BA Einleitung
The product has the following features:
][Merkmale_Ein_Aus INC  Inputs for
– Counter pulses (inputs A, B)
– Zero pulse (Input C)
– Stopping the counter (Input G, Gate)
– Memory function (Input L, Latch)
– Rotary encoder status (Input S, Status)
 Resolution of the counter and latch memory: 32 Bit
 Operating modes:
– Incremental encoders
– Counters
 Inputs A, B, C are operated as differential inputs with inverted signals
(A-, B-, C-).
 Pulse multiplication (up to four times)
][Merkmale_LED INC  LEDs for:
– Data transfer per input A, B, C
– Status per functional input (Gate, Latch, Status)
– Module error
][Merkmale_Zusatz ST-Module Sys A + B  For standard applications in system environment A and B
][Geraetemerkmal_T  Coated version of the module:
PSSu E S INC-T: for increased environmental requirements
