2-1
2.1
Module structure
2
Overview
2
2000
Overview
Overview
2-
2.1
Module structure
2100
Module structure
2-
][BA bersicht Aufbau
A module consists of
Electronic module and
Base module with
– Screw terminals or
– Cage clamp terminals
The base modules are the carrier units for the electronic modules and
are used to connect the field wiring. The electronic modules are inserted
on to the base modules and determine the module's function.
Details of the base modules that can be used are available in the chapter
entitled “Intended Use”.
2.1.1
Module features
Module features
2-
][Merkmale_Versorgung PD
The module routes the periphery supply from the module bus to the
base module terminals.
][Merkmale_LED PD
LED for:
– Periphery supply
][Merkmale_Zusatz
Application range depends on the base module
][Geraetemerkmal_T
Coated version of the module:
PSSu E PD-T: for increased environmental requirements
