6.3 Connecting the module
6 Wiring
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]
6-4
6.3 Connecting the module 6300 Connecting the module 6- ][Anschluss RJ45
RJ45 interface Layout
RJ45 connector The connection cable PSSu A RJ45-
CAB 1.5M is available as an accesso-
ry.
8 1
Shield
