4 FORM NO. L-20007-K-0913
GENERAL SPECIFICATIONS
GENERAL SAFETY PRECAUTIONS
Specifications:
Torque Up to 1130 Nm (10000 in-lbs)
Actuation Pressure 1 - 5.5 bar (14.5 - 80 psi)
Service Temperature 4.5 - 104 C (40 - 220 F)
Approximate Weight Up to 22 kg (49 lbs)
CAUTION
Use lifting aids and proper lifting
techniques when installing, removing,
or placing this product in service.
CAUTION
Watch for sharp features when
interacting with this product. The
parts have complex shapes and
machined edges.
CAUTION
Use appropriate guarding for moving
components. Failure to guard could
result in serious bodily injury.
WARNING
This product is capable of emitting
a spark if misused therefore is not
recommended for use in any explosive
environment.
WARNING
Ensure proper guarding of the product is
used. Nexen recommends the machine builder
design guarding in compliance with OSHA 29
CFR 1910 “Occupational Safety and Health
Hazards”.
CAUTION
This product has possible pinch
points. Care should be taken when
interacting with this product.
CAUTION
Use appropriate guarding for moving
components. Failure to guard could
result in serious bodily injury.
CAUTION
This product has possible pinch
points. Care should be taken when
interacting with this product.
CAUTION
The temperature limits for the
product are 4.5-100 degree
Celsius (40-220 degree F).
