7-14
Starting and operating
tial LSD torque as desired. When this
mode is selected, the “AUTO” indicator
light in the combination meter goes off.
Manual switch
Press the “DCCD-MANU” switch on the
center console to switch from auto mode
to manual mode. The “AUTO” indicator
light in the combination meter will go off.
Press the switch again to go back to auto
mode. The “AUTO” indicator light in the
combination meter will come on.
Center differential control dial and
indicator light
The control dial is located beside the park-
ing-brake lever. By turning the control dial
forward and rearward, it is possible to
change the initial LSD torque.
The center-differential indicator lights in
the combination meter give six levels of in-
dication. The indicator lights and control
dial are linked; when the dial is turned to
change the initial LSD torque, the illumina-
tion position of the indicator lights chang-
es accordingly.
Turn the dial forward to increase the initial
LSD torque; when the white line on the
dial reaches the frontmost position, the ini-
tial LSD torque setting is maximum. The
center differential will then be almost com-
pletely locked and the “LOCK” indicator
light will come on.
MANU
700356
700125
700357
