AT-HD44M-S as master:
1. Connect all sources to HDMI Inputs on the 4x4 HDMI over CAT5 matrix master AT-HD44M-S
2. Connect each DDC output on the AT-HD44M-S to respective DDC input on the remote re-
ceiver AT-HD44M-R
3. Connect each TMDS output on the AT-HD44M-S to respective TMDS input on the remote
receiver AT-HD44M-R
4. Connect IR emitter cable to the AT-HD44M-S and direct the IR emitter to the build-in IR re-
ceiver of the sources
5. Connect the +5V 6A DC power supply to the AT-HD44M-S
6. Power on all HDMI sources
7. Power on the AT-HD44M-S
AT-HD44M-R as receiver:
1. Connect each HDMI output to HDMI displays
2. Connect the TMDS input on the AT-HD44M-R to the TMDS output on the AT-HD44M-S
3. Connect the DDC input on the AT-HD44M-R to the DDC output on the AT-HD44M-S
4. Connect IR receiver cable and place the IR receiver at the appropriate position that can re-
ceive the IR signals sent from the users
5. Use push button to adjust the EQ until the picture and sound are clear
