Atlona AT HD44M SR - Manual (Page 5)

2 3
1. 1x AT-HD44M-S
2. 1x IR emitter cable1
3. 2x Rack-mounting ears
4. 1x IR remote1
5. 1x User Manual
6. 4x AT-HD44M-R
7. 4x IR receiver cable
8. 8x Wall-mounting screws
9. 1x 5V 6A power adapter
1 Additional IR remote control and IR emitter cable can be purchased as optional accessories to control the HDMI
sources located separately.
PACKAGE CONTENTS:
CONNECTION DIAGRAM
HDMI Cable
IR Controller
HDMI Cable HDMI Cable
HDMI
Cable
HDMI
Cable
Cat5e Cable
PS3
Blu-Ray DVD STB
HDMI Camera
AT-HD44M-R
AT-HD44M-S
AT-HD44M-R AT-HD44M-R AT-HD44M-R
Cat5e Cable Cat5e Cable Cat5e Cable
HDTV HDTV HDTV HDTV
HDMI Cable HDMI Cable HDMI Cable
