Atlona AT HD44M SR - Manual (Page 17)

NOTICE
14 15
1. If the DVI or HDMI device requires the EDID information, please use EDID Reader/Writer to
retrieve and provide DVI/HDMI EDID information.
2. All HDMI over CAT5 transmission distances are measured using Belden 1583A CAT5e
125MHz LAN cable and ASTRODESIGN Video Signal Generator VG-859C.
3. The transmission length is largely affected by the type of LAN cables, the type of HDMI
sources, and the type of HDMI display. The testing result shows solid LAN cables (usually
in bulk cable 300m/1000ft form) can transmit a lot longer signals than stranded LAN cables
(usually in patch cord form). Shielded STP cables are better suit than unshielded UTP ca-
bles. A solid UTP CAT5e cable shows longer transmission length than stranded STP CAT6
cable. For long extension users, solid LAN cables are your only choice.
4. EIA/TIA-568-B termination (T568B) for LAN cables is recommended for better performance.
5. To reduce the interference among the unshielded twisted pairs of wires in LAN cable, you
can use shielded LAN cables to improve EMI problems, which is worsen in long transmis-
sion.
6. Because the quality of the LAN cables has the major effects in how long transmission dis-
tance will be made and how good is the received display, the actual transmission length is
subject to your LAN cables. For resolution greater than 1080i or 1280x1024, a CAT6 cable is
recommended.
7. If your HDMI display has multiple HDMI inputs, it is found that the first HDMI input [HDMI
input #1] generally can produce better transmission performance among all HDMI inputs.
8. The AT-HD44M-SR has been tested extensively and found that it doesn’t require external
power supply. If in rare situation you find it cannot work with the AT-HD44M-SR, please use
any +5V power adapter to plug in the power jack and see if it can work. If not, please contact
your technical support for further service.
9. Additional IR remote controls and IR emitter cables can be purchased as optional accesso-
ries to control the HDMI sources located separately.
Performance Guide for HDMI over LAN Cable Transmission
Performance rating Type of LAN cable
Wiring Shielding CAT5 CAT5e CAT6
Solid Unshielded (UTP) *** **** *****
Shielded (STP) *** *** ****
Stranded Unshielded (UTP) * ** **
Shielded (STP) * * **
Termination Please use EIA/TIA-568-B termination (T568B) at any time
