User's Manual CA 106
KLING & FREITAG GMBH ©1995 - 2006 Version 5.1, 09.11.2006 Page 21 of 26
13. Technical Specifications
Loudspeaker
Design 2-way passive system, bass reflex tuning
Frequency range -10 dB 78 Hz - 22 kHz
Frequency range ±3 dB 88 Hz - 20 kHz
Coverage angles (nominal) 90° x 60° (hor. x vert.)
Directivity index (DI) 10 (+1.5/-2) 1.5 kHz - 15 kHz
Power handling (nominal) 120 W
SPL 2.83 V / 1m 92 dB
Max. SPL 118 dB (SPL peak / 1 m)
Components 6.5‘‘ low-mid chassis
1‘‘ high frequency driver on rotatable
90° x 60° CD-horn
Crossover 1.8 kHz / octave, self-resetting
protection circuit for 6.5" and
1" chassis
Impedance (nominal) 16
Ω,
Connectors 2 x Speakon NL4MP (1+ / 1-)
Enclosure
Multifunctional enclosure with monitor and
cluster angles, 12 mm Finnish birch Multiplex
with highly resistant black or white structured
paint (PU)
2 x M6 and 8 x M8 thread inserts,
ball proof front grille with exchangeable
black or grey (white) acoustic foam
Dimensions (W x H x D) 195 x 365 x 206.5 mm
Weight 7 kg
Options '100 Volt with 50/100/150 VA
toroidal transformer (8.7 kg)'
'terminal clamp instead of Speakon connector’
Shielded Light', magnetically shielded,
lightweight version (5.4 kg),
'Outdoor Mobile'
'Special finish in RAL colours'
Accessories see catalogue or visit www.kling-freitag.de
