Dimensions & Weight
Height Front (cm) 28.5/8” (72.6)
Width (cm) 17.3/4” (45.1)
Depth (cm) 13.1/8” (33.4)
Weight (Kg) 54.5 lbs (24.8)
Weight (Kg) with Crossover 58.5 lbs (26.6)
Box Shape
Anisometric Hexagon
Box Finish
Textured Water Borne Acrylic
Hardware Finish
Polyester Sandtex™ Powder
Protective grille
18 Gauge Steel & foam
Horn Configuration
Fiberglass Waveguide
Cabinet Construction
Rugged 11 ply 5/8” Baltic Birch
Options
1,114 Pantone colours
Frequency Response (+/-3dB)
Full Range Preset 55Hz - 18kHz
Frequency Range
with Xover Preset 90Hz - 18kHz
Maximum SPL
(Xover Preset: High Pass @80Hz) (Continuous / Peak)
Passive with Full Range Preset 122.6dB / 128.6dB
Passive with Xover Preset 125.5dB / 131.5dB
Active with Full Range Preset 127.6dB / 133.6dB
Active with Xover Preset 129.4dB / 135.4dB
Directivity
Horizontal x Vertical 40°x 20° / 60°x 40° / 90°x 60°
Sensitivity (2.83V @ 1m)
LF 102.7 dB
HF 108.15 dB
LF/MF Section (Impedance Ω)
15” ND15L Neodymium Kevlar
Mid-Bass driver (6Ω)
HF Section (Impedance Ω)
3” B&C DE 800 1.4” exit
compression driver (16Ω)
Power Handling
(AES / Program / Peak)
LF 500 /1000 /2000
HF 110 / 220 / 440
Connection
2 x Neutrik Speakon™ NL4
connectors
The Side Lock Revolver (SLR™) rigging system promotes flexibility in
setup even in the most Dali-esque venues with difficult coverage
areas. All cabinets use discreet SLR™sockets placed on 4 sides of
the enclosure, available for use with all Point series rigging methods
offered. The Point 12’s can be hung side by side using the SLR™
Butterfly Brackets™ and SLR™ Super Sight Mount™, or in a single or
double vertical pair configuration, using the SLR Articulator™. Both
systems allow full individual box rotation for vertical angle control
with a pull of the Quick-lock™ pin, and horizontal angle control
with a single manually adjustable knob (special-order only) or a
Philips head screw.
Built-in Rigging Features:
2 Sets of SLR™ Sockets, Built-in Polemount Socket, 4 x 5/16 -18
threads for Omni Mount 60 Series
Optional Rigging Parts:
SLR™ Quick-Lock™ Components:
Vertical & Horizontal Bracket™, Butterfly Bracket™,
Articulator™
SLR™ Components:
Sight Mount Bracket™, Extended Sight Mount Bracket™, Super
Sight Mount Bracket™
SLR™ Polemount Components:
Polemount Base™ for Quick-Lock™ Horizontal Brackets™
SLR™ C-Clamp Components:
Quick-Lock™ 360° Articulator™, Fixed Base™
SLR™ Underhang Components:
Use 2 x Vertical Brackets™ or 2 x Butterfly Brackets™
with an Articulator™ for a 2 or 4-box Array.
SLR™ Monitor Mode Components:
Wedger™
*please refer to the Point Series user manual
for details on all SLR
™
rigging systems and parts.
Specifications are subject to change without notice.
