Adamson Point Series - Manual (Page 12)

The Side Lock Revolver (SLR™) rigging system promotes flexibility
in setup even in the most Dali-esque venues with difficult
coverage areas. All cabinets use discreet SLR™sockets placed
on 4 sides of the enclosure, available for use with practically
all Point series rigging methods offered. The Point 115 Subs can
be arrayed using the SLR™ Sight Mount™, Quick-Lock™ 360°
Articulator™, or one below the other with SLR™ Underhang
system, in settings such as dance clubs where space might be
an issue. SLR™systems allow full box rotation for horizontal control
with a pull of the Quick-lock™ pin, and vertical angle control with
a single manually adjustable knob (special-order only) or a Philips
head screw.
Built-in Rigging Features:
2 Sets of SLR™ Sockets, Built-in Polemount Socket, 4 x 5/16 -18
threads for Omni Mount 60 Series
Optional Rigging Parts:
SLR™ Quick-Lock™ Components:
Vertical & Horizontal Bracket™, Articulator™
SLR™ Components:
Sight Mount Bracket™, Extended Sight Mount Bracket™, Super
Sight Mount Bracket™
SLR™ Polemount Components:
Polemount Base™ for Point Subs
SLR™ C-Clamp Components:
Quick-Lock™ 360° Articulator™, Fixed Base™
SLR™ Underhang Components:
Point 115 Sub to Point 8 Bracket
(Left & Right) or use with
2 x Point 115 Sub.
*please refer to the Point Series user manual for details on all
SLR™ rigging systems and parts.
Dimensions & Weight
Height Front (cm) 16.1/2” (41.9)
Width (cm) 17.3/4” (45.1)
Depth (cm) 13.1/8” (33.4)
Weight (Kg) 38.5 lbs (17.5)
Weight (Kg) with Crossover 43.5lbs (19.8)
Box Shape Symmetrical Rectangle slightly
curved front
Box Finish
Hardware Finish Textured Water Borne Acrylic
Polyester Sandtex™ Powder
Protective grille 18 Gauge Steel & foam
Cabinet Construction Rugged 11 ply 5/8” Baltic Birch
Options 1,114 Pantone colours
Frequency Response (+/-3dB)
Full Range Preset 55Hz - 200Hz
Frequency Range
with Xover Preset 50Hz - 135Hz
Maximum SPL (Continuous)
with Xover Preset TBA
with Full Range Preset TBA
Maximum SPL (Peak)
Xover Preset TBA
Full Range Preset TBA
Sensitivity (2.83V @ 1m)
LF 95 dB
LF Section (Impedance Ω) 15” ND15S Neodymium Kevlar
Mid-Bass driver (6Ω)
Power Handling (AES / Program / Peak)
LF 500 /1000 /2000
Connection 2 x Neutrik Speakon™ NL4
connectors
Specifications are subject to change without notice.
Adamson Systems Engineering
1401 Scugog Line 6, Port Perry,
ON L9L 1B2, Canada
t: [905] 982 0520 f: [905] 982 0609
www.adamsonsystems.com
[email protected]
TECHNICAL DATA
technical specifications
RIGGING FEATURES PHYSICAL DATA
