1
Description
VideoCompositor is a high-end Crestron Smart Graphics™ component (SmartObject™) designed to help
developers build sophisticated drag-and-drop graphical user interfaces for controlling the Analog Way
LiveCore™ series in Crestron environment. This module will make video composition an interactive and
entertaining task on many Crestron compliant touchscreen.
Requirements
This module LiveCore™ is supported by 2 and 3 series Crestron’s processors as long as these processors
provide an Ethernet connection. It will only work with Smart Graphics compliant panels such as TSX Series
(TSW, TST, ...), TSD2020, TPMC-V Series (V12, V15, V24), DGE-1, DGE-2, Smart Graphics™ XPanel and web
XPanel, windows surface pro (windows 8.1 with adobe air 3.5). Apple iPad, Apple iPhone and Android are
not supported yet.
Note: Due to limited performances, TSX panels are not recommended to handle a large number of layers,
especially if dynamic snapshots are required in the user interface.
Minimum software versions:
Software Versions
SIMPL Windows 4.02
VTPro-e 5.3.19
Smart Graphics™ 2.00.19.00
Device database 52.00.007.00
Crestron database 41.05.006.00
Simlp+ cross compiler 1.3
Module main features

Visualization in real time of a screen content (Preview and/or Program) with layer positions and
source snapshots

Layer source management through drag and drop

Capability to change position and size of a layer through a tap or flick of a finger

Support multi-projector Soft Edge blending (up to 3 projectors)

Customizable look and feel

Source panel becomes automatically scrollable when the number of sources exceeds panel bound

All layers are automatically resized when the output resolution changes

Source panel can be locked in order to restrict users for changing the source assigned to a layer

Layers repositioning and resizing can be disabled

Layers z-order can be modified by the control system

Layers rectangle can be limited to the main layer rectangle
