Analog Way AW VIDEOCOMPOSITOR - LIVECORE PLATFORM - Ref. AWVDC Smart Graphics module - Manual (Page 6)

5
Source Properties Description
Panel orientation The source panel orientation (vertical or horizontal)
Nb source per line /
Nb source per column The number of sources per line or per column depending on the
source panel orientation. If this value equals '0' or '1', the source will
be displayed in a single line or a single column, otherwise, the sources
will be distributed over multiple columns
Disable source join Disable the sources when the signal is high
Source dimension The source’s logo width and height in pixel
Source margin The gap in pixel between two sources. This can be a vertical margin if
the source panel orientation is vertical or a horizontal margin the
source panel orientation is horizontal
Number of sources Total number of sources
Hide source If checked, the source will not be displayed
Source name The source name
Source num This source identifier. This number will be sent to the control system
while dropping the source onto a target. A target receiving this
identifier will retrieve the corresponding source information
Remote image URL Used to display the source icon
Snapshot URL The dynamic source snapshot URL. This is the URL provided by the
Analog Way switcher for each source, frame and logo
Background Image Path The default source static image
