APC-3X17B User Manual 26
27. JP_104P:
(2.0mm Pitch 1X3 Pin Header) PC104+ port voltage selection jumper, select voltage
for PCI-104 Plus devices.
The default for this jumper is “all open”,meaning the
user must select the voltage to be used.
JP_104P Pin# PC104+ VIO Voltage
All Open Default
Close 1-2 +3.3V PCI Card
Close 2-3 +5V PCI Card
28. PC104+ (option):
(4x30 Pin), PC104 plus connector, it conforms to standard PC104+ specification. Can
expand support four PCI devices.
ASB-M801T/ET：PC104+ connector in the top.
ASB-M801B/EB：PC104+ connector in the Bottom.
29. PCIEX2 (option):
(4x10 Pin), PCIe bus connector, it conforms to standard PCI Express x1 specification.
Can expand support
two PCIe devices.
ASB-M801T/ET：PCIEX2 connector in the top.
ASB-M801B/EB：PCIEX2 connector in the Bottom.
MODEL PC104+ / PCIEX2
ASB-M801T Top
ASB-M801ET Top
ASB-M801B Bottom
ASB-M801EB Bottom
30. MPCIE1:
(Socket 52Pin),mini PCIe socket, it is located at the top, it supports mini PCIe devices
with USB2.0, SMBUS and PCIe signal. MPCIe card size is 30x30mm or 30x50.95mm.
31. JRI:
(2.0mm Pitch 1X3 Pin Header), Wake up setting jumper. pin 1~2 are used to select
signal for COM4 Wake up, pin 2~3 are used to select signal for PCI devices Wake up,
JRI Pin# Function
Close 1-2 PCI_PME for COM4
Close 2-3 PCI-PME for PCI
