Note: Due to limited address length of BIOS, only a portion of panel parameters are listed in
BIOS Setup. If the connected panel is not included in the parameter list, display
problem will occur. In this case, Please do not change BIOS setup
.
3.8.1 North Bridge Configuration
BIOS SETUP UTILITY
Chipset
North Bridge Chipset Configuration
ENABLE: Allow
Remapping of
Over lapped PCI Memory
Above the total
Physical memory
DISABLE: Do not allow
remapping of memory
← Select Screen
↑↓ Select Item
+- Charge Field
F1 General Help
F10 Save and Exit
ESC Exit
Memory Remap Feature
[Enabled]
PCI MMIO Allocation: 4Gb To 3072MB
Memory Hole
[Disabled]
Initate Graphic Adapter [PCI/IGD]
IGD Graphics Mode Select
[Enabled ,64MB]
IGD GTI Graphic smemory size [No VT
mode,2MB]
PEG Port Configuration
► Video Function Configuration
V02.61 © Copyright 1985-2006 American Mega trends , Inc.
Memory Remap Feature:
[Enabled]
[Disabled]
Memory Hole:
[Disabled]
[15MB-16MB]
Initate Graphic Adapter:
Select which graphics controller to use as the primary boot device.
