Modbus™ Communication
DECS-250N
Group
Name
Register
Type
Sz
R/W
Unit
Range
24
Secondary Definite Time Pickup
1
43282
Float
4
R W
n/a
0.5 – 6
24
Secondary Definite Time Pickup
2
43284
Float
4
R W
n/a
0.5 – 6
24
Secondary Definite Time Delay 1
43286
Float
4
R W
ms
50 – 600000
24
Secondary Definite Time Delay 2
43288
Float
4
R W
ms
50 – 600000
24
Secondary Inverse Time Pickup
43290
Float
4
R W
n/a
0.5 – 6
24
Secondary Time Dial Trip
43292
Float
4
R W
n/a
0 – 9.9
24
Secondary Time Dial Reset
43294
Float
4
R W
n/a
0 – 9.9
24
Curve Exponent
43296
Uint32
4
R W
n/a
0.5=0,1=1,2=2
Gains Settings
Table 33. Gains Settings Group Parameters
Name
Register
Type
Bytes
R/W
Unit
Range
Primary Gain Option
43800
Uint32
4
R W
n/a
T'do=1.0 Te=0.17=1 T'do=1.5 Te=0.25=2 T'do=2.0
Te=0.33=3 T'do=2.5 Te=0.42=4 T'do=3.0 Te=0.50=5
T'do=3.5 Te=0.58=6 T'do=4.0 Te=0.67=7 T'do=4.5
Te=0.75=8 T'do=5.0 Te=0.83=9 T'do=5.5 Te=0.92=10
T'do=6.0 Te=1.00=11 T'do=6.5 Te=1.08=12 T'do=7.0
Te=1.17=13 T'do=7.5 Te=1.25=14 T'do=8.0 Te=1.33=15
T'do=8.5 Te=1.42=16 T'do=9.0 Te=1.50=17 T'do=9.5
Te=1.58=18 T'do=10.0 Te=1.67=19 T'do=10.5 Te=1.75=20
Custom=21
Secondary Gain Option
43802
Uint32
4
R W
n/a
T'do=1.0 Te=0.17=1 T'do=1.5 Te=0.25=2 T'do=2.0
Te=0.33=3 T'do=2.5 Te=0.42=4 T'do=3.0 Te=0.50=5
T'do=3.5 Te=0.58=6 T'do=4.0 Te=0.67=7 T'do=4.5
Te=0.75=8 T'do=5.0 Te=0.83=9 T'do=5.5 Te=0.92=10
T'do=6.0 Te=1.00=11 T'do=6.5 Te=1.08=12 T'do=7.0
Te=1.17=13 T'do=7.5 Te=1.25=14 T'do=8.0 Te=1.33=15
T'do=8.5 Te=1.42=16 T'do=9.0 Te=1.50=17 T'do=9.5
Te=1.58=18 T'do=10.0 Te=1.67=19 T'do=10.5 Te=1.75=20
Custom=21
AVR Kp Primary
43804
Float
4
R W
n/a
0 - 1000
AVR Ki Primary
43806
Float
4
R W
n/a
0 - 1000
AVR Kd Primary
43808
Float
4
R W
n/a
0 - 1000
AVR Td Primary
43810
Float
4
R W
n/a
0 - 1
FCR Kp
43812
Float
4
R W
n/a
0 - 1000
FCR Ki
43814
Float
4
R W
n/a
0 - 1000
FCR Kd
43816
Float
4
R W
n/a
0 - 1000
FCR Td
43818
Float
4
R W
n/a
0 - 1
FVR Kp
43820
Float
4
R W
n/a
0 - 1000
FVR Ki
43822
Float
4
R W
n/a
0 - 1000
FVR Kd
43824
Float
4
R W
n/a
0 - 1000
FVR Td
43826
Float
4
R W
n/a
0 - 1
PF Ki
43828
Float
4
R W
n/a
0 - 1000
PF Kg
43830
Float
4
R W
n/a
0 - 1000
Var Ki
43832
Float
4
R W
n/a
0 - 1000
Var Kg
43834
Float
4
R W
n/a
0 - 1000
OEL Ki
43836
Float
4
R W
n/a
0 - 1000
OEL Kg
43838
Float
4
R W
n/a
0 - 1000
UEL Ki
43840
Float
4
R W
n/a
0 - 1000
UEL Kg
43842
Float
4
R W
n/a
0 - 1000
SCL Ki
43844
Float
4
R W
n/a
0 - 1000
SCL Kg
43846
Float
4
R W
n/a
0 - 1000
Vm Kg
43848
Float
4
R W
n/a
0 - 1000
Inner Loop Kp
43850
Float
4
R W
n/a
0 - 1000
Inner Loop Ki
43852
Float
4
R W
n/a
0 - 1000
