Short Seam Automat 2110-4 / 2111-4 Workinging Instructions
- D 86 -
Beisler Automated Sewing Equipment
D.3
Programming
D.3.10 Level 2 special parameters / Lists
Setting stitch lengths and bar tacks:
All settings for the configuration of the seam can be chan-
ged using this list.
The minimum and maximum values of input are limited
by the program control unit. Values that are not within the
limits will not be accepted but reduced to the correspon-
ding minimum or maximum value.
•
Press
3 key.
The parameter list is shown on the display.
Parameters for clamp transport:
This list is used to make all settings for the clamp move-
ment.
•
Press
8 key.
The parameter list shown on the display has the following
function:
01 Clamp insertion as seen from right end of rail
02 Stop position 600 mm is a safety value. Only values
higher than 600 mm can be input
03 Settable range: 35 % - 80 %
04 Settable range: 35 % - 99 %
05 Range of the curve where no sewing is performed. If
value "0" is input here, the sewing process starts im-
mediately.
