BUG-O Systems Piper-Plus - Manual (Page 90)

90
SECTION 18.0 WIRING DIAGRAMS / PENDANT WIRING
PWS-0238
SWT-1003
CNN-5H06
SWT-1004
CNN-5H06
SWT-1113
(GRN)
SWT-1111
(BLK) CNN-5H06
CNN-5036-P
CNN-5036-P
CNN-5035-P
CNN-5035-P
MDS-2102
CNN-5H06
A C B
HEAT SHRINK
SWT-1112
(RED)
CNN-5H06
SWT-1114
(YEL)
CNN-5H06
1 5
6 10
CNN-5H05
CNN-5003-P
(CRIMP SIDE SHOWN)
(6) CNN-5016-P, PINS 2,3,4,6,7,8,
(4) CNN-5017-P, PINS 1,5,9,10
V+
GND
CAN H
CAN L
CAN GND
PWS-0239
PWS-0240
PWS-0241
Figure 18.5
Figure 18.6
Figure 18.7
Figure 18.8
