Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com GU-139-J page 19 of 29
IA4100
Administrator Guide
Programming Commands (continued)
Programming Buttons and Inputs
Command Explanation Format Default
31 Button 1 (RED) 31<phone number>
Ý
<output(s)>
Ý
<recording(s)># 123
Ý
13
Ý
1#
32 Button 2 (BLACK) 32<phone number>
Ý
<output(s)>
Ý
<recording(s)># 0456
Ý
2
Ý
#
33 Button 3 33<phone number>
Ý
<output(s)>
Ý
<recording(s)>#
ÝÝ
#
34 Button 4 34<phone number>
Ý
<output(s)>
Ý
<recording(s)>#
ÝÝ
#
35 Input 1 35<button># 0#
36 Input 2 36<button># 0#
37 Loss of AC power 37<phone number>
Ý
<output(s)>
Ý
<recording(s)># 7
ÝÝ
7#
38 Low battery 38<phone number>
Ý
<output(s)>
Ý
<recording(s)># 8
ÝÝ
8#
39 PAS Fault 39<phone number>
Ý
<output(s)>
Ý
<recording(s)># 9
ÝÝ
9#
NOTES: For Programming Phone Numbers, see Commands 01 to 09 (page 5).
If the first phone number slot entered is zero and a keypad (i.e., FP2-K faceplate) is
connected, then this button (other than RED) will activate as manual call mode. Or if
entering a number slot (e.g., 31123 ÝÝ # or 32456 ÝÝ #) has a phone number pro-
grammed and a keypad is present, the number will be auto dialed. Upon the call being
detected and answered by voice message (auto attendant), the user is allowed keypad
access to dial a number allowed by system.
For setting outputs 1 through 3 on, see Programming Outputs, Commands 11 to 13 (page 5).
For recorded messages, see Programming Recordings 1 through 9, see Commands 21 to 29
(page 5).
A message will play over the speaker immediately after a button press in the order in
which they were programmed.
For Input Commands 35 and 36, the input associated with the button is as follows:
0 = disabled
1 to 4 = button 1 to 4
Voltage controlled relays = 9-32 volts AC or DC
(Continued on next page)
