Maintenance and Troubleshooting
4-11
4.11 Replacement Parts List
The following tables contain some of the items that may need to be replaced in these
displays over a period of time. Many of the parts within the display also list their part
numbers on labels affixed to them.
To prevent theft Daktronics recommends purchasing a lockable cabinet to store
manuals and replacement/spare parts.
Part Description
Part Number
Controller Galaxy 8 Conn
0A-1229-0009
Power Supply 133/171 Red
0A-1320-0702
Power Supply 133/171 Amber
0A-1320-0703
Thermostat Enclosure 85 Closed 65 Open
0A-1327-3101
Digital Light Sensor
0A-1241-4013
Fan
B-1019
(120V Displays)
T-1119
Filter, RFI Line 20
AMP
120 VAC
Z-1007
Fan Finger Guard
HS-1130
Ribbon Assy; 20 pos, 84”
0A-1000-0023
Ribbon Assy; 20 pos, 108”
0A-1000-0025
Manual; Venus 1500 Operator’s, Version 3.0
ED13530
Cable; 22 AWG (Light Sensor/Temp Sensor to Controller)
W-1234
Digital Temp Sensor
0P-1247-0008
Electrical Contact Cleaner Lubricant / Cal-Lube
CH-1019
Module, AF-3400-7X4-133-R
0A-1320-2000
Module, AF-3400-8X4-133-A
0A-1320-2011
Module, AF-3400-7X4-171-R
0A-1320-2100
Module, AF-3400-7X4-171-A
0A-1320-2101
4.12 Daktronics Exchange and Repair and Return
Programs
To serve customers' repair and maintenance needs, Daktronics offers both an
Exchange Program and a Repair and Return Program.
Daktronics' unique Exchange Program is a quick, economical service for replacing
key components in need of repair. If a component fails, Daktronics sends the
customer a replacement, and the customer, in turn, sends the failed component to
Daktronics. This not only saves money, but also decreases display downtime.
Daktronics provides these plans to ensure users get the most from their Daktronics
products, and it offers the service to qualified customers who follow the program
guidelines explained below. Please call the Help Desk – 877-605-1113 – if you have
questions regarding the Exchange Program or any other Daktronics service.
