Chapter 2 Hardware Installation
14
Chapter 2
LVDS Switch Setting
JP5 (Channel B)
JP6 (Channel A)
1
3
2
1
3
2
1
3
2
1
3
2
1-2 On: High
2-3 On: Low (default)
2-3 On: Low
1-2 On: High (default)
Important:
You need to set JP5 and JP6 simultaneously.
JP5 and JP6 are designed to select the signal for the LVDS panel.
