Expansion Slots • 1 PCIe x4 slot
• 1 SDIO socket
WatchDog
Timer
• Watchdog timeout programmable via software from 1 to 255 seconds
Damage Free
Intelligence
• Monitors system temperature and overheat alarm
• Monitors system fan speed and failure alarm
ROM Interface • 1 SPI interface
- Supports up to 64Mbit
Temperature • Operating: 0 o C to 60 o C
• Storage: -20 o C to 85 o C
Humidity • 5% to 90%
Board to Board
Connector
• One MXM connector
Dimensions • Mini-ITX form factor
• 170mm (6.7") x 170mm (6.7")
Chapter 1 - Introduction
Specifications (For BT700/BT701 Only)
Graphics • Display ports
- 1 dual channel LVDS
- 1 DP port
Audio • Realtek ALC886 5.1-channel High Defi nition Audio
• Audio outputs: Mic-in/Center+Subwoofer, Line-in/Surround and Line-out
USB • 1 USB 3.0 and 6 USB 2.0 ports
Storage • 1 SATA 3.0 port with data transfer rate up to 6Gb/s
- SATA port provides adequate space for SATA DOM
• 1 mSATA port
Rear Panel IO
Ports
• 1 12V DC-in jack
• 2 DB-9 RS232 serial ports
• 1 DP port
• 1 RJ45 LAN port
• 1 USB 3.0 port
• 2 USB 2.0 type A ports
• Mic-in/Center+Subwoofer, Line-in/Surround and Line-out jacks
I/O Connectors • 1 connector for 2 external USB 2.0/1.1 ports
• 2 UART ports
- 1 supports TX/RX signal only (UART 2)
• 1 LVDS LCD panel connector
• 1 LCD/inverter power connector
• 1 Serial ATA connector
• 1 Serial ATA power connector
• 1 mSATA port
• 1 LPC connector
• 1 I
2 C connector
• 1 SMBus connector
• 1 CAN-bus connector
• 1 front panel connector
• 3 fan connectors
