www.dfi .com
40
Chapter 3 BIOS Setup
Chapter 3
PC Health Status
This section displays the hardware health monitor.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
PC Health Status
 Smart Fan Function
Case Open
CPU Temperature
System Temperature
CPU Fan Speed
System Fan 1 Speed
System Fan 2 Speed
VCore
+5V
+12V
+1.5V
+3.3V
3VSB
VBAT
Advanced
[Disabled]
: +57.0 C
: +32.5 C
: 1465 RPM
: N/A
: N/A
: +1.744 V
: +4.998 V
: +12.056 V
: +1.520 V
: +3.360 V
: +3.376 V
: +3.056 V
Smart Fan Function
Smart Fan Function
Setting
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save and Reset
ESC: Exit
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Advanced
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit


Smart Fan Function
CPU Smart Fan Control
Boundary 4
Boundary 3
Boundary 2
Boundary 1
Speed Count 5
Speed Count 4
Speed Count 3
Speed Count 2
Speed Count 1
System Smart Fan (1) Control
Boundary 4
Boundary 3
Boundary 2
Boundary 1
Speed Count 5
Speed Count 4
Speed Count 3
Speed Count 2
Speed Count 1
System Smart Fan (2) Control
Boundary 4
Boundary 3
Boundary 2
Boundary 1
Speed Count 5
Speed Count 4
Speed Count 3
Speed Count 2
Speed Count 1
[Enabled]
60
50
40
30
100
75
50
40
30
[Enabled]
60
50
40
30
100
75
50
40
30
[Enabled]
60
50
40
30
100
75
50
40
30
Enable CPU Smart Fan
CPU Smart Fan Control
When this feature is set to Automatic, the CPU’s fan speed will rotate according to the
CPU’s temperature. The higher the temperature, the faster the speed of rotation.
System Smart Fan Control
When this feature is set to Automatic, the System’s fan speed will rotate according to
the System’s temperature. The higher the temperature, the faster the speed of rota-
tion.
Boundary 1 to Boundary 4
The range is 0-127.
Speed Count 1 to Speed Count 5
The range is 1-100%.
Case Open
Sets this field to Enabled to allow the system to alert you of a chassis intrusion event.
