- SOME PARTS MAY HAVE BEEN
REMOVED FOR CLARITY.
NOTE:
- ENSURE LOCK OUTS (4 & 5) ARE
IN UPRIGHT POSITION BEFORE
INSTALLING WEIGHT CARRIAGE (14).
FRAME ASSEMBLY
PAGE 19
OWNER'S MANUAL
CF-3355 ASSEMBLY
5
FRAMES (8), AS SHOWN.
STEP1:
HORIZONTALLY BETWEEN SIDE
INSERT WEIGHT CARRIAGE (14)
ROTATE WEIGHT CARRIAGE (14)
90 DEGREES TO FIT INTO SIDE
FRAMES (8), AS SHOWN.
14
STEP 2:
4
