Hoist Fitness CF-3355 - Manual (Page 42)

ITEM NO. PART NUMBER DESCRIPTION QTY.
1 026-01X1488 1/2" LONG PULL-PIN (HARDENED) ASSEMBLY 1
2 026-01X5566 UPPER CROSSMEMBER 1
3 026-01X5567 BACK PAD MOUNT 1
4 026-01X5570 LOCK OUT -1 1
5 026-01X5571 LOCK OUT -2 1
6 026-01X5576 ADJUSTER - 1 1
7 026-01X5577 ADJUSTER-2 1
8 026-01X5615 SIDE FRAME 2
9 026-01X5616 FRONT TO REAR TIE - 1 1
10 026-01X5617 REAR UPRIGHT RIGHT-1 1
11 026-01X5618 REAR UPRIGHT RIGHT-2 1
12 026-01X5619 FRONT TO REAR TIE - 2 1
13 026-01X5620 LOWER CROSSMEMBER 1
14 026-01X5621 WEIGHT CARRIAGE 1
15 026-01X5622 LOCK OUT MOUNT, TOP 2
16 026-01X5623 SEAT FRAME 1
17 026-01X5625 FOOTPLATE MOUNT 1
18 026-01X5669 EXIT HANDLE 1
19 022-01PD2055 UPHOLSTERED HEAD PAD 1
20 022-01PD2336-A-M BACK PAD ASSEMBLY 1
21 022-01PD2073-5 HEAD PAD PLASTIC BACKING 1
22 022-01PD2335-A-M SEAT PAD ASSEMBLY 1
23 026-01F0300 FLNG-B, .188" X Ø3.00" X 6.25" LG. 2
24 026-01G0409 LINEAR ROD 49.88" LG. 2
25 026-01M2792 SHAFT - LIMITER 2
26 026-01M1185 WEIGHT HORN SHAFT 15.00"LG. 4
27 026-01M0932 ALUMINIUM CAP: Ø1.25" ID 3
28 026-01M0933 ALUMINUM RING: Ø1.25" ID 3
29 026-01M2764 SHAFT 1.00" X 3.94", BORED 3
30 026-01M2765 25MM BRNG HOUSING 4
31 026-01M2786 WEIGHT PEG 22.50" LG. 2
32 026-01M2787 WEIGHT PEG 17.50" LG. 2
33 026-01M2790 ROLLER 2
34 026-01M2809 FLANGED SHAFT CAP 2
35 026-01P5261 WASHER 3.00" OD X 1.53" ID X .188" T 4
PART LIST
PAGE 41 CF-3355 ASSEMBLY
OWNER'S MANUAL
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
