1
ORDERING PROCEDURE
2-10 HD1070 Product Configuration Manual
Specify the Leads Between the Power Supply and the Gas Console
The lead set contains two control cables that interface the power supply to the gas console.
Note that the hoses from the gas supply to the gas console are not provided by Hypertherm.
• Based on the distance (the path the leads will take) between the gas console and the power supply,
specify the appropriate part number.
Specify the PAC182 Torch
The torch for the HD1070 system is the PAC182. This torch comes with an off-valve sub-assembly and
15-amp consumables.
Hypertherm does not provide a torch mounting bracket for the PAC182. Precision cutting machines have
their own mounting brackets that have proven to be adequate for the HD1070 PAC182 torch.
Hypertherm also does not supply an initial height sensing (IHS) system for the PAC180 torch. If an initial
height sensing system is to be used, order the torch with an IHS tab on the shield cap.
• Before ordering the torch, determine if an IHS system is needed. Order the appropriate part number from
page 2-11.
Specify the Consumable Parts Kit
There is one parts kit for all PAC182 consumables. This kit contains electrodes, nozzles and shields for
15-amp, 30-amp, 50-amp and 70-amp cutting.
• Order the consumable parts kit.
8a
8
7
