7 55
Maintenance
Instrument panel fuse panel
Description
Fuse rating
Protected component
AUDIO 1
10A
Audio, A/V & Navigation Head Module
ROOM LP
(MEMORY FUSE)
10A
BCM, Auto Light & Photo Sensor, Room Lamp, Driver/Passenger Vanity Lamp Switch,
Date Link Connector, Door warning Switch, RF Receiver, A/C Control Module, Luggage Lamp,
IPS Control Module, Instrument Cluster (IND.), Map Lamp, Electro Chromic Mirror
MODULE 2
10A
IPS Control Module, BCM, Electro Chromic Mirror, PDM
START
10A
Burglar Alarm Relay, E/R Fuse & Relay Box(Start Relay)
A/BAG IND
10A
Instrument Cluster (Air Bag IND.)
CLUSTER
10A
Audio, Console Switch, Instrument Cluster(IND.), BCM, Alternator, A/V & Navigation Head Module
MODULE 4
10A
E/R Fuse & Relay Box(Blower Relay), Cluster Ionizer, A/C Control Module, Sunroof Motor
POWER OUTLET 2
25A
Cigarette Lighter & Front Power Outlet, Rear Power Outlet
AUDIO 2
10A
Power Outside Mirror Switch, AMP, BCM, PDM, A/V & Navigation Head Module, Audio
A/BAG
10A
SRS Control Module, Passenger Occupant Detection Sensor
MODULE 1
10A
IPS Control Module, Tire Pressure Monitoring Module, EPS Control Module, Steering Angle Sensor,
ESC OFF Switch, DBC Switch, ICM Relay Box(DBC Relay), Multifunction Switch(Light),
Stop Lamp Switch, AWD ECM
FOG LP RR
10A
-
WIPER FRT
25A
Front Wiper Motor, Multifunction Switch(Wiper), E/R Fuse & Relay Box(Front Wiper Relay)
S/HEATER FRT
15A
Console Switch
POWER OUTLET 1
15A
Cigarette Lighter & Front Power Outlet
