Hyundai 2008 Elantra - Manual (Page 89)

Features of your vehicle
16 4
Auto up/down window (if equipped)
(Driver's window)
Depressing or pulling up the power win-
dow switch momentarily to the second
detent position (6) completely lowers or
lifts the window even when the switch is
released. To stop the window at the
desired position while the window is in
operation, pull up or depress and release
the switch to the opposite direction of the
movement.
If the power window is not operating cor-
rectly, the automatic power window sys-
tem must be reset as follows:
1. Turn the ignition switch to the ON posi-
tion.
2. Close driver’s window and continue
pulling up on driver’s power window
switch for at least 1 second after the
window is completely closed.
Automatic reversal
If the upward movement of the driver’s
window is blocked by an object or part of
the body, the window will detect the
resistance and will stop upward move-
ment. The window will then lower approx-
imately 12 in. (30 cm) to allow the object
to be cleared.
If the window detects resistance while
the power window switch is pulled up
continuously, the window will stop
upward movement then lower approxi-
mately 1in. (2.5cm). If the power window
switch is pulled up continuously again
within 5 seconds after the window is low-
ered by the automatic window reversal
feature, the automatic window reversal
will not operate.
WARNING
• The automatic reverse feature for
the driver’s window is only active
when the “auto up” feature is
used by fully pulling up the
switch.
The automatic reverse
feature will not operate if the win-
dow is raised using the halfway
position on the power window
switch.
• Always check for obstructions
before raising any window to
avoid injuries or vehicle damage.
If an object less than 0.16 in. (4
mm) in diameter is caught
between the window glass and
the upper window channel, the
automatic reverse window may
not detect the resistance and will
not stop and reverse direction.
