36 SI-60E User Manual
Chipset Settings
This section allows you to configure and improve your system and allows you to set up some
system features according to your preference.
Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
► PCH-IO Configuration
► System Agent (SA) Configuration
PCH-IO Configuration
This section allows you to configure the North Bridge Chipset.
Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
Intel PCH RC Version
1.8.0.0
→ ← Select Screen
↑↓Select Item
Enter: Select
+- Change Opt.
F1:General Help
F2:Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Intel PCH SKU Name Q87
Intel PCH Rev ID 05/C2
► PCI Express Configuration
► USB Configuration
► PCH Azalia Configuration
PCH LAN Controller
Wake on LAN
Enabled
Enabled
PCH LAN Controller
Enable or disable onboard NIC.
Wake on LAN
Enable or disable integrated LAN to wake the system. (The Wake On LAN cannot be
disabled if ME is on at Sx state.)
