IHSE USA 474 Series Draco major - Manual (Page 60)

Draco major
60 2011-10-11
Configuration in the Java Tool
Configurations and system settings via Java tool can only be done in
offline mode without a direct connection between matrix and Java tool.
To activate a created configuration in the matrix, proceed as follows:
1. Select
File > Upload to
in the menu bar. Enter the IP address of the
matrix (see Chapter 5.3.4, Page 79) and the name and password of
the user identification and select the storage location of the new
configuration (default or config01-08) in the menu Select
Configuration
.
2. Select
Switch > Connect
in the menu bar and enter the IP address of
the matrix and the name and password of the user identification ein.
3. Select
Administration > Activate Configuration
in the task area
and select the storage location that has been selected in point 1.
4. Use the button Activate to load the selected configuration in the
matrix. The connection and the open tab will be closed and the matrix
will be restarted.
During the activation of a configuration, the matrix is temporarily not
available.
