4 – Master 5000/0227 44 ©
COPYRIGHT KEMPPI OY
P21
P22
P23
R22
S21
R21
P21 Current meter
P22 Voltage meter
P23 Display for adjustment value of MMA welding dynamics -9..0...9
R21 Ajustment of welding current
R22 Adjustment of MMA welding dynamics
S21 Selection for local/remote control
Do not use faulty welding cables. Isolate yourself by using dry and not worn out protective
clothes. Do not weld on wet ground. Do not place the welding cables on the power source or
other electricial equipment.
Watch the welding fumes!
Ensure that there is suffi cient ventilation. Follow special safety measures when you weld metals
which contain lead, cadmium, zinc, mercury and beryllium.
Note the danger caused by special welding jobs!
Watch the fi re and explosion danger when welding container type work pieces.
2. INSTALLATION
2.1. INSTALLATION
