5. Description of controls
5.1 The front panel
All the commands and controls for the cooking hob and oven are on the front panel.
CONTROL PANEL
DESCRIPTION OF HOB BURNER KNOB
The flame is lit by simultaneously pressing and turning the knob anticlockwise to
the low flame symbol .
To regulate the flow of the flame, turn the knob to between the maximum and
minimum settings. Turn off the burner by returning the knob to position .
LAYOUT OF BURNERS – Description of symbols
REAR LEFT
REAR RIGHT
REAR CENTRE LEFT
REAR CENTRE RIGHT
CENTRE FRONT
CENTRE REAR
FRONT CENTRE LEFT
FRONT CENTRE RIGHT
FRONT LEFT
FRONT RIGHT
