4
Installation
All the operations concerned with the installation
(electrical and gas connections, adaptation to type of
gas, necessary adjustments, etc.) must be carried out
by qualified technicians, in terms with the standards
in force. For specific instructions, kindly read the part
reserved for the installation technician.
Use
Standby mode (Fig. 1-2-3)
When the device is turned on, it performs a brief self-test
and calibrates the touch-pad (all displays and LEDs turn
on for several seconds). At the end, the display will be
completely off. In this mode, the device can be turned on
by simply pressing the ON/OFF key.
Turning on the Cooking Surface
To turn on the device, you must hold down the ON/
OFF key for at least 2 seconds. The device will turn on
and the burner displays will display level zero, which
corresponds to burner off.
Turning on a burner
To turn on a burner, press the relative + and - keys on the
control panel. The keys must be pressed simultaneously
and held down for at least 1 second. When the burner
turns on, the burner will be set to the average flow and
the relative display will show level 3.
Each burner whose timer has not been programmed
will automatically turn off after 4 hours of continuous
operation.
The turning on of the burner is also indicated by the
relative LED near the timer display, which will be on for
the entire time that the burner is on.
Adjusting the flame level of a burner
To increase the flow to a burner that is on, press the
+ key and to decrease the flow, press the - key. For a
continuous change in the flow level, just hold down the +
or - key and release it at the desired level. The flow level
varies from 1 to 5.
Turning off a burner
To turn a burner off, press the + and - keys simultaneously
for a brief instant.
Turning off all the burners
To turn all the burners off at the same time, briefly press
the ON/OFF key; this puts the device in standby mode.
Programming the amount of time after which the
burner turns off
A time, after which a burner turns off, can be set
independently for each burner.
To program a burner timer, press the PT key. In the
part of the control panel that shows the position of each
burner with an LED, the burner A indicator (LED-A)
lights to indicate that burner A is currently selected for
programming. Use the P+ and P- keys to select the timer
of the burner to be programmed. The selected burner is
indicated by the flashing of its light. The timer display
shows 0.00 to indicate that the timer for the selected
burner is not active. To program the turn-off time for
the selected burner, press the PT key again; the timer
display will show 0.00. The flashing digit to the left of the
decimal point indicates hours while the digits to the right
indicate minutes. By pressing the P+ or P- keys, you can
increase, or decrease, the number of operating hours
from 0 to 9. When you hold down the P+ or P- keys, the
change of hours is continuous.
To specify the number of minutes, press PT again. The
digit to the right of the decimal point flashes. Set the
minutes the same way as the hours.
When programming the time, you can zero the current
setting at any time by pressing the P+ and P- keys
together. When a time of zero is set, the burner timer is
deactivated. To confirm the time displayed, press the PT
key. At this point, the only burner LEDs that are flashing
are those whose timers are running.
By pressing the PT key, you can return to timer
programming mode to see how much time remains
before the burner turns off or to change the current
setting. If, during programming, no key is pressed for
longer than 10 seconds, programming is automatically
interrupted and the main display returns. Any settings
that were made for the selected burner are stored and
the relative timer is running.
A timer can be set whether a burner is on or off and
the countdown starts immediately after the time setting
is confirmed. When the timer reaches zero, the timed
burner will be turned off and, at the same time, there
will be a beep.
When you turn off a burner, its timer is also deactivated.
Setting the clock
After a power failure, the time displayed by the clock
inside the device must be reset.
To set the clock, you must press the PT, P+ and P- keys
simultaneously for at least 3 seconds.
The flashing digit to the left of the decimal point indicates
hours while the digits to the right indicate minutes.
Pressing the P+ or P- keys increases or decreases the
hours and, when you hold down the P+ or P- key, the
number of hours changes continuously.
Press the PT key again to set the minutes. The digits
to the right of the decimal point will flash and you can
Instructions for use
