Page 28
28
Parts List
REF
DESCRIPTION
VALUE
V/W
TOL.
MFR'S DESIG
VXSTD P/N
VERS.
LOT SIDE LAY ADR
Main Unit
R 1083
CHIP RES.
100k
1/16W
5%
RMC1/16S 104JTH
J24189049
1-
B
b3
R 1084
CHIP RES.
47
1/16W
5%
RMC1/16S 470JTH
J24189009
1-
B
b3
R 1085
CHIP RES.
220
1/16W
5%
RMC1/16S 221JTH
J24189017
1-
B
b3
R 1086
CHIP RES.
100k
1/16W
5%
RMC1/16S 104JTH
J24189049
1-
B
b2
R 1087
CHIP RES.
270k
1/16W
5%
RMC1/16S 274JTH
J24189054
1-
B
b3
R 1088
CHIP RES.
100k
1/16W
5%
RMC1/16S 104JTH
J24189049
1-
B
b3
R 1089
CHIP RES.
220k
1/16W
5%
RMC1/16S 224JTH
J24189053
1-
B
b3
R 1090
CHIP RES.
220
1/16W
5%
RMC1/16S 221JTH
J24189017
1
B
b3
R 1090
CHIP RES.
330
1/16W
5%
RMC1/16S 331JTH
J24189019
2-
B
b3
R 1091
CHIP RES.
220
1/16W
5%
RMC1/16S 221JTH
J24189017
1-
B
b2
R 1092
CHIP RES.
330
1/16W
5%
RMC1/16S 331JTH
J24189019
1-
B
b3
R 1093
CHIP RES.
330
1/16W
5%
RMC1/16S 331JTH
J24189019
1-
B
b3
R 1094
CHIP RES.
4.7k
1/16W
5%
RMC1/16S 472JTH
J24189033
1-
A
A4
R 1095
CHIP RES.
2.2k
1/16W
5%
RMC1/16S 222JTH
J24189029
1-
A
A4
R 1096
CHIP RES.
390k
1/16W
0.5%
MCR01MZPD3903
J24189331
1-
A
C5
R 1097
CHIP RES.
470k
1/16W
0.5%
MCR01MZPD4703
J24189332
1-
A
C5
R 1098
CHIP RES.
330k
1/16W
0.5%
MCR01MZPD3303
J24189330
1-
A
C5
R 1099
CHIP RES.
560k
1/16W
0.5%
MCR01MZPD5603
J24189335
1-
A
C5
R 1100
CHIP RES.
270k
1/16W
0.5%
MCR01MZPD2703
J24189329
1-
A
C5
R 1101
CHIP RES.
1M
1/16W
1%
MCR01MZSF1004
J24189333
1-
A
C5
R 1102
CHIP RES.
820k
1/16W
0.5%
MCR01MZPD8203
J24189336
1-
A
C5
R 1103
CHIP RES.
10k
1/16W
5%
RMC1/16S 103JTH
J24189037
1-
A
C5
R 1104
CHIP RES.
47
1/16W
5%
RMC1/16S 470JTH
J24189009
1-
A
C1
R 1105
CHIP RES.
4.7k
1/16W
5%
RMC1/16S 472JTH
J24189033
1-
A
C4
R 1106
CHIP RES.
2.2k
1/16W
5%
RMC1/16S 222JTH
J24189029
1-
A
B4
R 1107
CHIP RES.
4.7k
1/16W
5%
RMC1/16S 472JTH
J24189033
1-
A
B4
R 1108
CHIP RES.
470k
1/16W
5%
RMC1/16S 474JTH
J24189057
1-
A
B4
R 1109
CHIP RES.
470
1/16W
5%
RMC1/16S 471JTH
J24189021
1-
A
C3
R 1110
CHIP RES.
470
1/16W
5%
RMC1/16S 471JTH
J24189021
1-
A
B3
R 1111
CHIP RES.
470
1/16W
5%
RMC1/16S 471JTH
J24189021
1-
B
a3
R 1112
CHIP RES.
470k
1/16W
5%
RMC1/16S 474JTH
J24189057
1-
B
a3
R 1113
CHIP RES.
270k
1/16W
0.5%
MCR01MZPD2703
J24189329
1-
A
B4
R 1114
CHIP RES.
100k
1/16W
0.5%
RR0510R-104-D
J24189167
1-
A
B4
R 1115
CHIP RES.
4.7k
1/16W
5%
RMC1/16S 472JTH
J24189033
1-
A
C4
R 1116
CHIP RES.
10k
1/16W
5%
RMC1/16S 103JTH
J24189037
1-
A
B4
R 1117
CHIP RES.
10k
1/16W
5%
RMC1/16S 103JTH
J24189037
1-
A
C4
R 1118
CHIP RES.
470
1/16W
5%
RMC1/16S 471JTH
J24189021
1-
B
a3
R 1119
CHIP RES.
470
1/16W
5%
RMC1/16S 471JTH
J24189021
1-
B
a3
R 1120
CHIP RES.
100k
1/16W
5%
RMC1/16S 104JTH
J24189049
1-
B
a3
R 1121
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
C4
R 1123
CHIP RES.
10k
1/16W
5%
RMC1/16S 103JTH
J24189037
1-
A
C4
R 1124
CHIP RES.
100
1/16W
5%
RMC1/16S 101JTH
J24189013
1-
B
a2
R 1125
CHIP RES.
470k
1/16W
5%
RMC1/16S 474JTH
J24189057
1-
B
a3
R 1126
CHIP RES.
150k
1/16W
5%
RMC1/16S 154JTH
J24189051
1-
B
c5
R 1127
CHIP RES.
100k
1/16W
5%
RMC1/16S 104JTH
J24189049
1-
B
b5
R 1128
CHIP RES.
100
1/16W
5%
RMC1/16S 101JTH
J24189013
1-
B
b4
R 1129
CHIP RES.
100
1/16W
5%
RMC1/16S 101JTH
J24189013
1-
B
b5
R 1130
CHIP RES.
560
1/16W
5%
RMC1/16S 561JTH
J24189022
1-
B
c4
R 1131
CHIP RES.
120k
1/16W
5%
RMC1/16S 124JTH
J24189050
1-
B
c4
R 1132
CHIP RES.
330k
1/16W
5%
RMC1/16S 334JTH
J24189055
1-
B
c4
R 1133
CHIP RES.
100
1/16W
5%
RMC1/16S 101JTH
J24189013
1-
B
a4
R 1134
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
B
a4
R 1135
CHIP RES.
330
1/16W
5%
RMC1/16S 331JTH
J24189019
1-
B
a2
R 1136
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
B
a3
R 1137
CHIP RES.
10k
1/16W
5%
RMC1/16S 103JTH
J24189037
1-
B
b4
R 1138
CHIP RES.
33k
1/16W
5%
RMC1/16S 333JTH
J24189043
1-
B
b3
R 1139
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
B
b4
R 1140
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
B
b4
R 1141
CHIP RES.
100k
1/16W
5%
RMC1/16S 104JTH
J24189049
1-
B
c4
R 1142
CHIP RES.
3.3k
1/16W
5%
RMC1/16S 332JTH
J24189031
1-
B
c4
R 1143
CHIP RES.
10k
1/16W
5%
RMC1/16S 103JTH
J24189037
1-
B
c4
R 1144
CHIP RES.
680
1/16W
5%
RMC1/16S 681JTH
J24189023
1-
B
c4
R 1145
CHIP RES.
1M
1/16W
5%
RMC1/16S 105JTH
J24189061
1-
B
c4
R 1146
CHIP RES.
100k
1/16W
5%
RMC1/16S 104JTH
J24189049
1-
B
c4
R 1147
CHIP RES.
10k
1/16W
5%
RMC1/16S 103JTH
J24189037
1-
B
b4
R 1148
CHIP RES.
47k
1/16W
5%
RMC1/16S 473JTH
J24189045
1-
B
b4
R 1157
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
B
a4
R 1158
CHIP RES.
100k
1/16W
5%
RMC1/16S 104JTH
J24189049
1-
B
a4
R 1159
CHIP RES.
0
1/16W
5%
RMC1/16S JPTH
J24189070
1-
B
a4
R 1160
CHIP RES.
220
1/16W
5%
RMC1/16S 221JTH
J24189017
1-
B
a4
R 1161
CHIP RES.
22k
1/16W
5%
RMC1/16S 223JTH
J24189041
1-
B
a5
R 1162
CHIP RES.
100
1/16W
5%
RMC1/16S 101JTH
J24189013
1-
B
a5
R 1163
CHIP RES.
100
1/16W
5%
RMC1/16S 101JTH
J24189013
1-
B
a5
