Page 29

Advertising
background image

29

R 1164

CHIP RES.

10k

1/16W

5%

RMC1/16S 103JTH

J24189037

1-

B

a5

R 1165

CHIP RES.

10k

1/16W

5%

RMC1/16S 103JTH

J24189037

1-

B

a4

R 1166

CHIP RES.

10k

1/16W

5%

RMC1/16S 103JTH

J24189037

1-

B

a4

R 1167

CHIP RES.

18k

1/16W

5%

RMC1/16S 183JTH

J24189040

1-

B

b3

R 1168

CHIP RES.

1k

1/16W

5%

RMC1/16S 102JTH

J24189025

1-

B

b4

R 1169

CHIP RES.

1.2k

1/16W

5%

RMC1/16S 122JTH

J24189026

1-

B

c4

R 1170

CHIP RES.

1.5k

1/16W

5%

RMC1/16S 152JTH

J24189027

1-

B

c4

R 1171

CHIP RES.

1.8k

1/16W

5%

RMC1/16S 182JTH

J24189028

1-

B

c4

R 1172

CHIP RES.

1k

1/16W

5%

RMC1/16S 102JTH

J24189025

1-

B

c4

R 1173

CHIP RES.

3.3k

1/16W

5%

RMC1/16S 332JTH

J24189031

1-

B

c4

R 1174

CHIP RES.

2.2k

1/16W

5%

RMC1/16S 222JTH

J24189029

1-

B

c4

R 1175

CHIP RES.

1k

1/16W

5%

RMC1/16S 102JTH

J24189025

1-

B

c5

R 1176

CHIP RES.

0

1/16W

5%

RMC1/16S JPTH

J24189070

1-

B

c3

R 1183

CHIP RES.

330k

1/16W

5%

RMC1/16S 334JTH

J24189055

1-

B

b4

R 1184

CHIP RES.

3.3k

1/16W

5%

RMC1/16S 332JTH

J24189031

1-

B

b3

R 1185

CHIP RES.

10k

1/16W

5%

RMC1/16S 103JTH

J24189037

1-

B

b4

R 1186

CHIP RES.

680

1/16W

5%

RMC1/16S 681JTH

J24189023

1-

B

a4

R 1187

CHIP RES.

22k

1/16W

5%

RMC1/16S 223JTH

J24189041

1-

B

a4

R 1188

CHIP RES.

4.7k

1/16W

5%

RMC1/16S 472JTH

J24189033

1-

B

b4

R 1189

CHIP RES.

10k

1/16W

5%

RMC1/16S 103JTH

J24189037

1-

B

a5

R 1190

CHIP RES.

1k

1/16W

5%

RMC1/16S 102JTH

J24189025

1-

B

a4

R 1191

CHIP RES.

220

1/16W

5%

RMC1/16S 221JTH

J24189017

1-

B

b5

R 1192

CHIP RES.

1k

1/16W

5%

RMC1/16S 102JTH

J24189025

1-

A

A4

R 1193

CHIP RES.

10k

1/16W

5%

RMC1/16S 103JTH

J24189037

1-

B

b3

R 1194

CHIP RES.

4.7k

1/16W

5%

RMC1/16S 472JTH

J24189033

1-

A

A4

R 1195

CHIP RES.

100

1/16W

5%

RMC1/16S 101JTH

J24189013

1-

B

c3

R 1202

CHIP RES.

3.3k

1/16W

5%

RMC1/16S 332JTH

J24189031

1-

B

b3

R 1203

CHIP RES.

330k

1/16W

5%

RMC1/16S 334JTH

J24189055

1-

B

b3

R 1204

CHIP RES.

3.3k

1/16W

5%

RMC1/16S 332JTH

J24189031

1-

B

a4

R 1205

CHIP RES.

1k

1/16W

5%

RMC1/16S 102JTH

J24189025

1-

B

a3

R 1206

CHIP RES.

10k

1/16W

5%

RMC1/16S 103JTH

J24189037

1-

B

b4

R 1207

CHIP RES.

330k

1/16W

5%

RMC1/16S 334JTH

J24189055

1-

B

b4

R 1208

CHIP RES.

1k

1/16W

5%

RMC1/16S 102JTH

J24189025

1-

A

A4

R 1209

CHIP RES.

10k

1/16W

5%

RMC1/16S 103JTH

J24189037

1-

A

B4

R 1210

CHIP RES.

1k

1/16W

5%

RMC1/16S 102JTH

J24189025

1-

A

A4

R 1216

CHIP RES.

100k

1/16W

5%

RMC1/16S 104JTH

J24189049

1-

B

a3

R 1217

CHIP RES.

100k

1/16W

5%

RMC1/16S 104JTH

J24189049

1-

B

a3

R 1219

CHIP RES.

330k

1/16W

5%

RMC1/16S 334JTH

J24189055

1-

B

b4

R 1220

CHIP RES.

15k

1/16W

5%

RMC1/16S 153JTH

J24189039

1-

B

b4

R 1221

CHIP RES.

180k

1/16W

5%

RMC1/16S 184JTH

J24189052

1-

B

a3

R 1222

CHIP RES.

100k

1/16W

5%

RMC1/16S 104JTH

J24189049

1-

B

b4

R 1223

CHIP RES.

10k

1/16W

5%

RMC1/16S 103JTH

J24189037

1-

B

b4

R 1224

CHIP RES.

47k

1/16W

5%

RMC1/16S 473JTH

J24189045

1-

A

C3

R 1225

CHIP RES.

100k

1/16W

5%

RMC1/16S 104JTH

J24189049

1-

A

C2

R 1226

CHIP RES.

1M

1/16W

5%

RMC1/16S 105JTH

J24189061

1-

A

C2

R 1227

CHIP RES.

47k

1/16W

5%

RMC1/16S 473JTH

J24189045

1-

A

C2

R 1228

CHIP RES.

330k

1/16W

0.5%

MCR01MZPD3303

J24189330

1-

A

C2

R 1230

CHIP RES.

330k

1/16W

5%

RMC1/16S 334JTH

J24189055

1-

A

C2

R 1231

CHIP RES.

68k

1/16W

0.5%

RR0510R-683-D

J24189163

1-

A

C2

R 1232

CHIP RES.

10k

1/16W

5%

RMC1/16S 103JTH

J24189037

1-

A

B4

R 1234

CHIP RES.

470k

1/16W

5%

RMC1/16S 474JTH

J24189057

1-

A

B4

R 1235

CHIP RES.

220

1/16W

5%

RMC1/16S 221JTH

J24189017

1-

B

c2

R 1236

CHIP RES.

220

1/16W

5%

RMC1/16S 221JTH

J24189017

1-

B

c2

R 1237

CHIP RES.

22k

1/16W

5%

RMC1/16S 223JTH

J24189041

1-

A

C2

R 1238

CHIP RES.

22k

1/16W

5%

RMC1/16S 223JTH

J24189041

1-

A

C2

R 1239

CHIP RES.

2.7k

1/16W

5%

RMC1/16S 272JTH

J24189030

1-

A

B4

R 1240

CHIP RES.

100

1/16W

5%

RMC1/16S 101JTH

J24189013

1-

A

B5

R 1241

CHIP RES.

10k

1/16W

5%

RMC1/16S 103JTH

J24189037

1-

A

B4

R 1242

CHIP RES.

33k

1/16W

5%

RMC1/16S 333JTH

J24189043

1-

A

B5

R 1243

CHIP RES.

150k

1/16W

5%

RMC1/16S 154JTH

J24189051

1-

A

B4

R 1244

CHIP RES.

68k

1/16W

5%

RMC1/16S 683JTH

J24189047

1-

A

C2

R 1245

CHIP RES.

33k

1/16W

5%

RMC1/16S 333JTH

J24189043

1-

A

C2

R 1247

CHIP RES.

22

1/16W

5%

RMC1/16S 220JTH

J24189005

1-

B

b2

R 1248

CHIP RES.

0

1/16W

5%

RMC1/16S JPTH

J24189070

1-

A

C2

R 1249

CHIP RES.

4.7k

1/16W

5%

RMC1/16S 472JTH

J24189033

1-

A

C3

R 1250

CHIP RES.

1.5k

1/16W

5%

RMC1/16S 152JTH

J24189027

1-

A

B5

R 1251

CHIP RES.

2.2M

1/16W

5%

RMC1/16S 225JTH

J24189065

1-

A

B5

R 1252

CHIP RES.

100k

1/16W

5%

RMC1/16S 104JTH

J24189049

1-

A

B5

R 1253

CHIP RES.

470k

1/16W

5%

RMC1/16S 474JTH

J24189057

1-

A

B3

R 1254

CHIP RES.

0

1/16W

5%

RMC1/16S JPTH

J24189070

VER.USA A2

1-

R 1254

CHIP RES.

0

1/16W

5%

RMC1/16S JPTH

J24189070

VER. A1

1-

R 1254

CHIP RES.

0

1/16W

5%

RMC1/16S JPTH

J24189070

VER. A2

1-

R 1254

CHIP RES.

0

1/16W

5%

RMC1/16S JPTH

J24189070

VER. B1

1-

Parts List

REF

DESCRIPTION

VALUE

V/W

TOL.

MFR'S DESIG

VXSTD P/N

VERS.

LOT SIDE LAY ADR

Main Unit
