5.0 SPECIFICATIONS
Power consumption
Icc: +5V quiescent 130 mA typical, 180 mA max
Icc: +12V quiescent 50 mA typical, 75 mA max
Icc:
−
12V quiescent 30 mA typical, 45 mA max
Analog Output section
D/A converter type AD7237
Resolution 12 bits
Number of channels 6
Ranges ±10V, ±5V, 0 to 10V, 0 to 5V each channel
individually jumper selectable
D/A pacing Software
Data transfer Software polled
Throughput 125 kHz typical (PC-dependent)
Offset error Adjustable to zero
Gain error Adjustable to zero
Integral non-linearity ±0.5 LSB
Differential non-linearity ±0.5 LSB
Monotonicity Guaranteed over temperature range
Gain drift 160 ppm/°C
Zero drift 150 ppm/°C
Current Drive ±5 mA min
Short circuit current ±40 mA
Output resistance 0.1ohms
Slew rate 1.7V/µs
Miscellaneous Double buffered input latches
Update DACs individually or simultaneously
(jumper selectable by DAC pairs)
DAC output state on power-up and reset
undefined
Environmental
Operating temperature range 0 to 70°C
Storage temperature range
−
40 to 100°C
Humidity 0 to 90% non-condensing
